640-1600A 3P 70kA h1600 LSI MCCB

Moulded case circuit breakers (MCCB's)

High fault level moulded case circuit breakers

LSI: adjustable thermal 0.4 - 1 x In / fixed magnetic 2.5 - 8 x Ir / time 0.1 - 0.2sec

4 pole availble on request

Hagers range of moulded case circuit breakers MCCBs provides safe and easy solutions for low voltage electrical circuit protection. The state of the art circuit breakers offer both designers and installers a wide range of features and benefits. With configurations of 3 and 4 pole offered across the range all sizes of MCCB's have an extensive range of internal and external accessories available such as; auxiliary switches, shunt trips, undervoltage releases, terminal kits, terminal shields, locking kits and rotary handles.

Benefits

• Ease of installation
• Simple set up fo maximum installation efficiency
• Quick, easy and safe mounting of accessories
• Wide range of rated current ratings and breaking capacities
• Range of termination accessories
• DIN rail profile up to 250A

Technical data

• 6 frame sizes: x160, x250, h250, h630, h1000, h1600
• Breaking capacity: 25, 40, 50, 70kA
• TM trip unit: 25 to 400A
• LSI trip unit: 250 to 1600A
• Comply with IEC 60947-2
• Current limiting type
• International certification and approvals
