OPT. FIBRE AMPLIFIER PNP 12-24VDC

Name: OPT. FIBRE AMPLIFIER PNP 12-24VDC
SKU: 22823
Price: 3818.00 ZAR
Availability: InStock

SKU FX102P-Z

R 3 818.00incl. VAT

Quantity:

Specifications

Category: Automation
Sub-category: Fibre-optic & Laser sensors
Product code: FX102P-Z
Type: Inventory Item
SERIES: FX
OUTPUT TYPE: PNP
Sub Category: Fibre-optic & Laser sensors
CONFIGURATION: NO+NC
Pricing Group: CAT K

Detailed Description

FX series fibre-optic amplifiers

PANASONIC has developed a new top price fibre sensor. The quick set mode allows inexperienced operators to use the sensor quickly. For experienced operators, the setting and PRO mode are available.

Key features:

Easy to read
Key-lock function
Teaching, light-ON / dark-ON setting
One 4-digit green, one 4-digit red LCD display
Direct installation possible without bracket or DIN rail
Commercially available connector simplifies procurement
Threshold values can automatically adjust to changes in incident light
No need to connect amplifiers in case interference prevention is requested
Intensity of emitted light can be reduced automatically to ensure stable sensing
Designed in a 3-layer structure to accomodate basic through advanced settings

SERIES	FX series
DESCRIPTION	Dependant on fibre used
SUPPLY VOLTAGE	12 - 24 VDC
PNP	Yes
NPN	No
LIGHT-ON	Yes
DARK-ON	Yes
CONNECTOR	M8 plug (4 pin)
SENSITIVITY SETTING	2-point teaching / Limit teaching / Full-auto teaching
TIMER FUNCTION	ON-delay, OFF-delay, no timer (selectable) 1 - 1000 ms
LED INDICATION	Orange LED when output is ON / Red and Green 4 digit display
INDEX PROTECTION	IP40
MOUNTING	DIN rail mounting or side mounting with 3.2 mm screws
DIMENSIONS (MM)	(H) 32 x (W) 9 x (D) 66.4
