Power Distribution & Control · Miniature circuit breakers
STEP RELAY 16A 2NO 12VAC
SKU EPN521
R 420.44incl. VAT
Quantity:
1
Specifications
- Category
- Power Distribution & Control
- Sub-category
- Miniature circuit breakers
- Product code
- EPN521
- Type
- Inventory Item
- Sub Category
- Miniature circuit breakers
- CONFIGURATION
- 2NO
- Pricing Group
- CAT B1
- CURRENT RATING
- 16A
- SUPPLY VOLTAGE
- 12VAC
- NUMBER OF POLES
- 2
- WIDTH IN 17.5MM
- 1
Detailed Description
Modular stepping relays
- Pulsing the relay changes the contact status until pulsed again
- Max. pulse duration: 1 hour
- With manual override facility
| RATED POWER AC-1 (A) | 16A |
| COIL VOLTAGE | 12 VDC |
| DESCRIPTION | Modular stepping relay |
| CONTACT CONFIGURATION | 2 NO |
| WIDTH IN 17.5MM | 1 |
| CONNECTION CROSS-SECTION RIGID CABLE | 1.5 / 10mm² |
| CONNECTION CROSS-SECTION FLEXIBLE CABLE | 1 / 6mm² |
| OPERATING TEMPERATURE | -5 to 40 °C |
| FREQUENCY | 50/60 Hz |
| PROTECTION INDEX IP | IP20 |
