STAR DELTA TIMER 230VAC
SKU DSD230A
R 863.88incl. VAT
Quantity:
1
Specifications
- Category
- Timers & Control Relays
- Sub-category
- Modular timing devices
- Product code
- DSD230A
- Type
- Inventory Item
- RANGE
- 30s-60s
- Sub Category
- Modular timing devices
- Pricing Group
- CAT J
- CURRENT RATING
- 10A
- SUPPLY VOLTAGE
- 220VAC
- WIDTH IN 17.5MM
- 2
Detailed Description
Star / Delta Timer - DSD
The Electro D range of control and timing devices are compact modular units for easy introduction into standard panels and/or distribution boards. They mount directly onto DIN rail and align with standard miniature circuit breakers (MCB's).
Multi-range Star / Delta timer with adjustable transition delay for starting inductive motors. DIN rail mountable for front and back panel positioning.
Features:
- Microprocessor controlled
- Relay releases to failsafe neutral centre position
- Adjustable Star time: 30 - 60 sec
- Adjustable Transition time: 40 - 180sec
- Modular 35.5mm DIN rail mountable
- 6A SPDT output relay with neutral centre position
- LED indication for Star and Delta relay On
| DESCRIPTION | Star-Delta timer |
| TIME RANGE | 0.9 to 30 sec, 3 to 60 sec (with neutral) |
| ADJUSTABLE STAR TIME | 30 - 60 sec |
| ADJUSTABLE TRANSITION TIME | 40 - 180 ms |
| CONTACT | 2 x 6A SPDT |
| MECHANICAL LIFE | 10x106 cycles |
| PROTECTION INDEX IP | IP 20 |
| OPERATING TEMPERATURE | -10 to + 50°C |
| STORAGE TEMPERATURE | -50 to + 85°C |
| DIMENSIONS (MM) | (H) 92 x (W) 36 x (D) 64 |
