TEMP CONTROLLER+24HR CLOCK 230VAC
DDTCT230A
R 2 024.00 Incl VAT
(0 reviews)
Online ordering is temporarily unavailable. You can still browse this product or request a spec sheet.
Quantity:
1
Product Details
Category:Timers & Control Relays
Sub category:Protection relays & Monitoring devices
Product code:DDTCT230A
Type:Inventory Item
RANGE:0-9999m
Sub Category:Protection relays & Monitoring devices
Pricing Group:CAT J
CURRENT RATING:10A
SUPPLY VOLTAGE:230VAC
WIDTH IN 17.5MM:2
Detailed Description
Digital Temperature Controller
The Electro D range of control and timing devices are compact modular units for easy introduction into standard panels and/or distribution boards. They mount directly onto DIN rail and align with standard miniature circuit breakers (MCB's).
Multi-function four digit counter/timer designed with the latest microprocessor technology. Setup and ranges can be adjusted with an easy to access and control menu system to make all common function available. The counter can be configured to accept two proxy, one for up and the other for down count. Timer can be activated with proxy as well.
Features:
- Multi-range
- Multi-function
- 10A SPDT output relay
- User friendly menu system
- Microprocessor controlled
- Modular 53.5mm Din rail mountable
- Interface and power supply for NPN proxys
| DESCRIPTION | Temperature controller with 24 hour clock |
| CONTACT | 2 x 6A SPDT |
| RATED VOLTAGE | 250V |
| MECHANICAL LIFE | 10x106 cycles |
| PROTECTION INDEX IP | IP 20 |
| OPERATING TEMPERATURE | -10 to + 50°C |
| STORAGE TEMPERATURE | -50 to + 85°C |
| DIMENSIONS (MM) | (H) 92 x (W) 36 x (D) 64 |
