ETHERNET IP SAFETY EXPANTION UNIT

MOSAIC - Safety controllers

MOSAIC is a modular configurable safety controller capable of managing all safety functions of machinery or plants. Made up of a Master unit which can operate as a stand-alone device or control up to 14 expansion units in a system.

Capable of monitoring several safety sensors and signals such as: light curtains - photocells - laser scanners - emergency stops - electromechanical switches - safety door switches - magnetic switches - safety mats and edges - two-hand controls - hand grip switches - encoders and proximities for safety speed control - load cells - pressure switches - temperature, flow and level measurements.

General features:

• Power supply: 24V DC ± 20%
• Safety level: SIL 3, PL e, SILCL 3, Cat. 4
• Connections: Removable (screw terminal) blocks
• Dimensions: (H) 99 x (W) 22.5 x (D) 114 mm
• Mounting: DIN rail mounting according to EN 50022-35 standard

MOSAIC - Expansion modules

• Input/output expansion modules:Provides additional digital inputs and outputs to the master unit
• Status outputs:Provides additional non-safety outputs to the master unit
• Safety relays:Provides safety relay outputs with guided contacts
• Communication:For connection to the most common industrial Field-bus systems
