10A aM DIN NH000 FUSE LINK 690V
384015
R 208.15 Incl VAT
(0 reviews)
Online ordering is temporarily unavailable. You can still browse this product or request a spec sheet.
Quantity:
1
Product Details
Category:Power Distribution & Control
Sub category:Fuse links & Holders
Product code:384015
Type:Inventory Item
FUSE SIZE:NH000
Sub Category:Fuse links & Holders
Pricing Group:CAT B4
CURRENT RATING:10A
SUPPLY VOLTAGE:690V
BREAKING CAPACITY:80kA
Detailed Description
aM (motor protection) fuse links (top indicator)
aM class (NH) for motor protection. These high breaking capacity fuse-links are intended for short circuit protection in motors, transformers and other loads with high inrush currents, with rated voltages up to 500 VAC (120kA) and 690 VAC (80kA). They offer excellent protection of switchgear (contactor, thermal overloads) due to the good current limiting capability and low I2t values.
| RATED CURRENT | 10A |
| RATED VOLTAGE | 690V |
| BREAKING CAPACITY | 80kA |
| CLASS | aM |
| FUSE SIZE | NH000 |
| DESCRIPTION | aM NH motor protection HRC DIN fuse link |
| CONFORMITY TO STANDARDS | IEC/EN 60269-1, IEC/EN 60269-2, DIN 43620 |
